NISSAN PATROL FITMENT
Nissan Patrol Wheels
Lenso 17 inch and 18 inch 4x4 wheels built to fit the Nissan Patrol. Every wheel on this page comes in the Patrol 6x139.7 stud pattern, with offsets to suit a factory look, a flush stance or a wider flared build.
Aftermarket Wheels and Rims for Your Patrol
The Nissan Patrol has built a serious reputation as one of Australia's toughest touring and off-road platforms, and swapping the factory rims for a set of aftermarket mag wheels is one of the easiest ways to get more out of it. Whether you are chasing a tougher look around town, more tyre choice for remote touring, or extra load capacity after a GVM upgrade, Lenso has a Patrol wheel to suit.
From the factory, Patrol wheel sizes have grown with each generation, from 15x7 and 16x7 on the GQ, up to 16 and 17 inch on the GU, and 18x8 or 20x8 on the Y62. Every Lenso wheel listed on this page matches the Patrol stud pattern.
| Spec | GQ Patrol | GU Patrol | Y62 Patrol |
|---|---|---|---|
| Stud pattern (PCD) | 6 x 139.7 | 6 x 139.7 | 6 x 139.7 |
| Centre bore | 110.1mm | 110.1mm | 78.1mm |
| Wheel nut thread | M12 x 1.25 | M12 x 1.25 | M14 x 1.5 |
| Factory offset (approx.) | +5 to +30 | +10 to +38 | +35 |
17" Patrol Wheels
17 inch is the go-to size for Patrol owners who spend real time off the bitumen. A 17 inch rim leaves room for a taller tyre sidewall, which means a softer ride over corrugations, better protection for the rim on rocks, and more room to air down on sand or dirt. Every 17 inch Lenso wheel below is a 17x9 in the Patrol 6x139.7 fitment.
Lenso Marvel 17x9
Our ultimate 4x4 wheel. Beadlock-style design, ultra brake clearance and a 1250kg load rating.
- 6x139.7
- Offsets: -12, 0, +18, +30
- From $348.00 per wheel
Lenso Dinero 17x9
Multi-spoke, deep dish look with a 1500kg load rating for serious touring and GVM builds.
- 6x139.7
- Offsets: -22, 0, +18, +35
- From $319.00 per wheel
Lenso Argo 17x9
Beadlock-style design with a sharp, aggressive centre face. 1250kg load rating.
- 6x139.7
- Offsets: +12, +30
- From $275.00 per wheel
Lenso Gravel 17x9
Beadlock-style design in three finishes, with ultra brake clearance.
- 6x139.7
- Offsets: +20, +30
- From $275.00 per wheel
Lenso Hurricane 17x9
Web spoke design with an innovative lip and a mega 1500kg load rating.
- 6x139.7
- Offsets: +12, +30
- From $275.00 per wheel
Lenso KAOS 17x9
Imitation beadlock with a bold machined finish and 1500kg load rating.
- 6x139.7
- Offsets: 0
- Pre-order, from $375.00 per wheel
Lenso Amada 17x9
Genuine beadlock for rock crawling and heavy-duty touring. 1250kg load rating at 0 and -22 offset, 1600kg at -38 and -12.
- 6x139.7
- Offsets: -38, -22, -12, 0
- Pre-order, not for on-road use, from $450.00 per wheel
18" Patrol Wheels
18 inch wheels fill out the guards and give the Patrol a sharper, more modern stance, especially on Y62 models already running 18s or 20s from the factory. Every 18 inch Lenso wheel below is an 18x9 in the Patrol 6x139.7 fitment.
Lenso Marvel 18x9
Our ultimate 4x4 wheel. Beadlock-style design, ultra brake clearance and a 1250kg load rating.
- 6x139.7
- Offsets: 0, +18, +30
Lenso Dinero 18x9
Multi-spoke, deep dish look with a 1500kg load rating for serious touring and GVM builds.
- 6x139.7
- Offsets: +18, +35
Lenso Cartel 18x9
Beadlock-inspired styling with a muscular centre face. 1500kg load rating. 18 inch only.
- 6x139.7
- Offsets: +18, +35
Lenso Argo 18x9
Beadlock-style design with a sharp, aggressive centre face. 1250kg load rating.
- 6x139.7
- Offsets: +12, +30
Lenso Gravel 18x9
Beadlock-style design in three finishes, with ultra brake clearance.
- 6x139.7
- Offsets: +20, +30
Lenso Hurricane 18x9
Web spoke design with an innovative lip and a mega 1500kg load rating.
- 6x139.7
- Offsets: +12, +30
Want to go bigger? The Lenso Marvel is also available in 20x9 +18 in the Patrol 6x139.7 fitment (Satin Black, Dirty Bronze and Graphite Grey).
17 vs 18 Inch Wheels on a Patrol
Both sizes bolt straight onto a Patrol. The right choice comes down to how you use it.
Choose 17 inch if you:
- Tour, camp or drive off-road regularly
- Want a taller sidewall for a softer ride and airing down
- Run a GQ or GU and want to stay closer to factory proportions
- Want the widest choice of AT and MT tyres
- Want a beadlock option (Amada)
Choose 18 inch if you:
- Spend most of your time on the road or towing
- Drive a Y62 already on 18s or 20s from the factory
- Want a modern look that fills the guards
- Want sharper steering feel on the highway
- Still want solid off-road ability on gravel and tracks
Patrol Wheel Offset Guide
Offset controls how far your wheel sits in or out of the guard. A lower number pushes the wheel further out for a wider, tougher stance.
| Offset | Look | Best for |
|---|---|---|
| +30 to +35 | Close to factory, sits neatly inside the guard | Stock Y62, daily driving, towing |
| +18 to +20 | Slightly wider, near flush with the guard | A tougher stance without flares |
| +12 | Wider, fills the guard | Mild lift and bigger tyres |
| 0 and negative | Deep dish, pokes past the guard | Flared and lifted builds, off-road and show builds |
Australian vehicle standards generally limit how much wider your track can go (commonly 25mm per side) before modifications need engineering. Rules vary by state, so check with your local authority or talk to our team if you are running a low or negative offset.
Lenso Patrol Wheel Fitment Chart
Every Lenso 4x4 wheel available in the Nissan Patrol 6x139.7 fitment, at a glance.
| Wheel | 17x9 offsets | 18x9 offsets | Load rating | Finishes |
|---|---|---|---|---|
| Marvel | -12, 0, +18, +30 | 0, +18, +30 | 1250kg | Satin Black, Dirty Bronze, Graphite Grey, Full Polished |
| Dinero | -22, 0, +18, +35 | +18, +35 | 1500kg | Satin Black, Dirty Bronze, Graphite Grey |
| Cartel | n/a | +18, +35 | 1500kg | Hyper Black, Satin Black |
| Argo | +12, +30 | +12, +30 | 1250kg | Satin Black, Dirty Bronze, Graphite Grey, Full Machined |
| Gravel | +20, +30 | +20, +30 | Ask our team | Satin Black, Copper Tint, Passion Black |
| Hurricane | +12, +30 | +12, +30 | 1500kg | Satin Black |
| KAOS (pre-order) | 0 | n/a | 1500kg | Full Machined, Machined Black Ring, Satin Black Machined Ring |
| Amada (beadlock, pre-order) | -38, -22, -12, 0 | n/a | 1250kg (0, -22) / 1600kg (-38, -12) | Full Machined, Machined Face Black Ring, Satin Black Machined Ring |
Available offsets can vary by finish and stock. Check the product page for current options, or call us on 1800 453 676. The Amada is a genuine beadlock wheel and is not for on-road use.
Why Patrol Owners Choose Lenso
Built for Australian Conditions
Every Lenso wheel is made from premium-grade aluminium and tested to perform reliably on Australian roads.
Rated for GVM Upgrades
With load ratings from 1250kg up to 1600kg per wheel, our 4x4 range is built for GVM upgrades and heavy-duty touring setups.
Ultra Brake Clearance
Our Marvel, Dinero, Cartel, Argo, Gravel and Hurricane wheels are all designed with ultra brake clearance.
Lifetime Warranty
Every Lenso wheel supplied in Australia comes with our Lifetime Warranty Program, plus Australia wide delivery on all wheel sets.
Nissan Patrol Wheels FAQs
What size wheels and rims fit a Nissan Patrol?
Every Lenso Patrol wheel on this page comes in 17x9 or 18x9, in the correct 6x139.7 stud pattern for GQ, GU and Y62 models. A 20x9 Marvel is also available for Patrol owners after a bigger look.
Do the same wheels fit a GQ, GU and Y62?
The stud pattern (6x139.7) is identical across all three, so yes, the same wheel will bolt up. Centre bore and wheel nut thread do change on the Y62 (78.1mm bore, M14x1.5 thread, versus 110.1mm and M12x1.25 on GQ/GU), so check with our team if you're unsure which generation you're fitting.
Are 17 or 18 inch wheels better for a Patrol?
17 inch suits touring, off-roading and a taller sidewall for a softer ride. 18 inch suits a Y62 already on factory 18s or 20s, and owners who want a sharper on-road feel while still keeping solid off-road ability.
What offset is best for a Nissan Patrol?
It depends on your generation and build. Close to factory offset keeps the wheel tucked in the guard, lower or negative offsets push the wheel out for a wider stance, best suited to flared or lifted builds. See our offset guide above.
Will 17x9 or 18x9 wheels rub on a Patrol?
Most standard Patrol builds run these sizes without rubbing at factory or near-factory offsets. Lower offsets, bigger tyres or a lowered suspension can change that, so talk to our team about your exact setup before you order.
Do Lenso wheels suit a Patrol with a GVM upgrade?
Yes. Our Dinero, Hurricane and KAOS wheels carry a 1500kg load rating, and the Amada beadlock goes up to 1600kg on its -38 and -12 offsets, all suited to GVM upgrades and heavy touring setups. Amada and KAOS are both currently pre-order.
Can I reuse my factory Patrol wheel nuts?
Not across generations. GQ and GU use M12 x 1.25 nuts, Y62 uses M14 x 1.5. New wheel nuts are included with every set purchased through Lenso.
Do these wheels fit a Patrol with a GU to Y62 wheel swap?
The stud pattern matches, but centre bore and thread size don't carry across generations. Give our team a call to confirm hub-centric fitment before ordering.
Not Sure Which Wheel Suits Your Patrol?
Tell us your model, year, tyre size and any lift or flares, and our team will help you pick the right Lenso wheel and offset. Need something different? Ask about our custom wheel fitments.
